T-BOX-U-Six (Single double public toilet)
T-BOX-U-Six
- The T-BOX-U-six is a large-capacity mobile restroom designed for high-traffic public areas and events.
- Measuring 4.2m × 2.6m × 3m with durable stainless steel flooring and HPL wall panels, it offers 4 unisex toilet compartments, 1 urinal room with 2 urinals, a utility room with rest space, and 5 sensor-activated wash basins.
- Equipped with central air conditioning, heating cables for water and pipelines, LED occupancy displays, ceiling speakers, and a one-touch emergency system, it ensures comfort, safety, and reliability.
- With an average of 1200 uses per cycle, 1L water-saving flush, and large-capacity septic and water tanks, the T-BOX-U-six delivers efficient, eco-friendly sanitation for modern urban needs.
Eco-Friendly Design
Comfortable Use
Safety & Accessibility
Durable Build
Parameters
Parameters
| Product | T-BOX-U-six (Single Unit with Six Compartments) |
| Size | Length 4.2m × Width 2.6m × Height 3m |
| Weight | 5000kg (for reference only, subject to actual weight) |
| Floor | SUS304 stainless steel patterned plate |
| Roof | Melamine warm white |
| Wall | Interior wall and ceiling with compact laminate board |
| Exterior panel | Fluorocarbon-coated aluminum composite panel |
| Glass material | Double-layer laminated tempered glass |
| Toilet | 4 (unisex) |
| Urinal compartment | 1 (with 2 urinals) |
| Utility room | 1 (used as rest room and power distribution box) |
| Wash basin | 5 (with automatic sensor faucets) |
| Air conditioning | Gree 1.5P central air conditioner (one-to-six) |
| Heating | Heating cables for water tank, septic tank, pipelines, faucets, etc. |
| Indicator | Occupied/vacant LED display with door control system |
| Audio | Built-in ceiling speakers |
| Emergency | One-touch help system |
| Usage capacity | Approx. 1200 uses per cycle |
| Consumption | 1L per flush (air-water mixed) |
| Capacity | Septic tank about 1.8m³; water tank about 1.2m³ |
